Vehicle Mounted Thermal Imaging Camera 640*512 9mm 15mm 20mm

Vehicle Mounted Thermal Imaging Camera 640*512  9mm 15mm 20mm
Vehicle Mounted Thermal Imaging Camera 640*512  9mm 15mm 20mm

Large Image :  Vehicle Mounted Thermal Imaging Camera 640*512 9mm 15mm 20mm

Product Details:
Place of Origin: China
Brand Name: Okaf
Certification: CE/FCC/RoHS
Model Number: OK-CT80RI-640-15
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Standard carton
Payment Terms: T/T, Paypal, Western Union, L/C, MoneyGram etc
Supply Ability: 2500pcs per month
Detailed Product Description
Product Name: Vehicle Mounted Thermal Imaging Camera 640*512 20mm Thermal Image Resolution: 640*512 / 384*288
Thermal Lens: 9mm / 15mm / 20mm Day Camera: 1920*1080P, 20x Optical Zoom
Feature: Small Size, Low Weight Detector: VOx Uncooled Detector
NETD: Less Than 50mk (@25℃F1.0 OEM/ODM: Welcome
High Light:

taxi cctv camera

,

hd cctv camera

Key Benefits:

Long range 24-hours monitoring.
Delicate and smooth images.
Convenient for installation and application.
360 degree of Omni-directional Pan-Tilt
Super-strong aluminum alloy with IP66
Higher sensitivity
Effective in all environments
Small size and low weight

Vehicle Mounted Thermal Imaging Camera 640*512  9mm 15mm 20mm 0



Overview:

VOx uncooled detector 640*512;
NETD is less than 50mk (@25℃F1.0);
SDE digital image processing, AGC, 2X digital amplification;
10 pseudo color and B/W, B/W inverse;
Intelligent functions: cross-border/ intrusion detection and target tracking;
255 level alarm threshold can be setup
Advanced algorithm support shot-point/ fire detection and alert;
One integral aluminum alloy housing, water proof, IP66 weather proof, anti-dust.



Applications:
Seaport and airport monitoring;
Water system monitoring;
Storage monitoring;
Oilfield & oil depot security;
Ecological and environmental monitoring;
Border and coastal defense;
Highways and railways monitoring.



Technical data



Model  OK-CT80RI-640-15
Detection Vehicle: 1400m / Human: 420m
Recognition Vehicle: 300 / Human: 120m
Thermal Camera
Sensor 5th generation FPA VOx Detector
Resolution 640*512 / 384*288
Spectral range 8~14μm
NETD 50mK (@25℃ F1.0)
Focal length 15mm F1.0
Field of view(horizontal)
Visible Camera
Imaging Sensor 1/2.8'' CMOS, Integrated ICR Dual Filter D/N Switch
Resolution 2 Mega pixels, 1920 x 1080
Illumination 0.05 Lux high sensitive color, 0.01 Lux black and white
Video Bit Rate 32Kbps-16Mbps, 60Hz 30 frames/second, ABF auto adjustment
Focal Length 5.4~108mm 20X zoom, 2 Megapixel electric focus
PTZ
Duty 10 kg
Rotation Pan: 0 - 360° continuously,Tilt: +90°~- 90°
Rotation speed Rotation speed:Pan: 0.01~100°/S,Tilt: 0.01~60°/S, support lens focusing speed adaptive
Accuracy 0.1°
Preset 255 presets, support lens zooming and focusing preset
Mode Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising
Network
Network interface RJ45.10, 10/100 Base-T adaptive (integrated video output RS422/485)
Network Protocol TCP/IP, UDP, IPv4/v6; support HTTP, RTP, RTSP, NFS, DHCP, NTP, SMTP, SNMPv1/v2c/v3, UPNP, PPPoE, DNS, FTP; support PSIA, ONVIF2.0, GB28181 and other network protocol.
Environment Parameter
Operating temperature -25℃~+60℃(-40℃ Optional)
Storage temperature -45℃~70℃
Protection Level IP66
General
Total Consumption 36W
Power supply DC12V V, anti-reverse connection protection
Weight ≤ 5kg (include PTZ)
