Product Details:
Payment & Shipping Terms:
|
| Video Compression: | H. 264 | G-Sensor: | Support G-sensor |
|---|---|---|---|
| Video Output: | 1xCVBS+1xVGA Output | Power Supply: | DC12V |
| OEM/ODM: | Welcome | Storage: | HDD/SSD+ SD Card |
| High Light: | vehicle dvr recorder,car mobile dvr |
||
One Channel Car DVR Kit 1080P 3G/4G/Wifi/GPS IP CCTV Car Mobile Video
Recorder
Product description:
1. Video Input: aviation connector,digital component signal access. NVR and PTZ camera are connected by special aviation cable, supporting 1 channel 1080P IP PTZ camera input.
2. Video Output:1 channel CVBS output, 1 channel VGA output,(1 channel aviation plug)
3. Main data rate:1080P/720P/WD1/4CIF,sub data rate:720P/WD1/4CIF/2CIF/CIF
4. Hard disc drive: support 1 2.5" HDD/SSD with SATA interface. The max. storage is 2T. Support 1 SD card at the same time, the max. storage is 128G.
5. External interface: 1 3G/4G aerial, 1 wifi aerial and 1 GPS aerial, all with SMA interface; 1 keyboard & display terminal interface, 1 intercom interface, 1 VGA interface, all with aviation interface
6. Support one 2.0 USB backup and upgrading; drawing type design; 3.0 USB backup built in.
7. 4G: communication module is detachable, fit all network.
8. Alarm input: 3 channels; alarm output: 2 channels
9. Power Supply: DC 8~36V
10. Working temperature:-25℃--＋70℃(excluding hard disk)
Parameters:
| Item | Parameter | |
| OS | Linux | |
| Language | Chinese/English/Others (can be customized) | |
| Video Compression | H.264 Compression Mode | |
| OSD | Overlays information such as date time and vehicle ID | |
| GUI | Graphical User Interface | Can connect to external LED screen. Setup system parameters with the remote control. |
| Video Record System | Video Input | 1CH 1080p input ,aviation connector. |
| Video Output | 1CH CVBS+ VGA output for optional, 1.0Vp-p, 75Ω | |
| Preview | Support 1 channel preview.,Support Manual/Alarm Trigger full screen preview | |
| Resolution | 1080p/720p/D1/HD1/CIF, MAX: 1 channel 1080p | |
| Video Quality | 0-7 levels, 0 is the highest level, 7 is the lowest level. | |
| Video Standard | CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional | |
| HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional | ||
| D1: 800Kbps ~ 3Mbps, multi levels video quality optional | ||
| 720P:4Mbps-6Mbps, multi levels video quality optional | ||
| 1080P:4Mbps-8Mbps, multi levels video quality optional | ||
| Record Mode | The default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported. | |
| Audio | Audio Input | 1CH |
| Audio Output | 1CH | |
| Compression | G.711 compression, 8KB/s speed | |
| Alarm Input | 8CH IO Alarm Input; Support alarm linkage function | |
| Alarm Output | 2CH power on/off Alarm Output, Support the linkage acousto-optic alarm, cut off fuel oil/power,etc | |
| Communication Interface | 2CH RS232, support extension device, such as POS machine, Oil Feul sensor, LED advertising screen , etc. | |
| 2CH 485 interface, can connect PTZ,etc. | ||
| 1CH CAN interface. | ||
| Wireless transfer | Support Built-in 3G/4G network, WCDMA,CDMA2000,TDD-LTE,FDD-LTE... | |
| TD-SCDMA Compatible with GPRS,EDGE | ||
| Position | Support Built GPS/BD Module,can make playback analysis of vehicle routing | |
| G-Sensor | Support G-sensor | |
| Video Storage | Storage | 2.5’’ HDD+ SD Card,each max 2TB HDD + 128GB SD Card mirror recording to protect data from loss |
| Upgrade | Support USB flash disk updating,SD card upgrade , OTA remote upgrade automatically | |
| File Format | .264 General video format | |
| File System | Professional MNVR File System | |
| USB | Front panel supports USB port, support USB flash disk upgrade to backup; hard disk box USB port, can back up video data | |
| Video Playback | Video Search | Search video by Record Time/Record Type etc |
| Playback | Max support 1CH Replay /Stop/Fast Forward/Fast Reverse at same time | |
| Support x 2,x4,x8,x16. fast forward or fast backward play | ||
| Safety Management | User/Admin 2 Levels Different Passwords , support screen lock | |
| Voltage & Power Consumption | Power Management | Adaptive wide power input, support Wide Voltage, Over-load,Over-voltage,Short Circuit,Reverse Protection..Support Time Setting/Delay power off |
| Voltage Input | DC:+8V ~ +36V | |
| Voltage Output | +12V@2.5A,+5V@2.5A | |
| Power-off Protection | UPS Technology,All video information can be saved automatically when the power is cut off, and make sure that all the files can not be damaged. | |
| Power Consumption | Normal Working ＜5W | |
| Working Environment | Temperature | -20℃ to +70℃ |
| Humidity | 20% to 80% | |
| others | Size | 187(D)* 188(W)* 67(H) mm |
| Net Weight | 1.8kg | |
