Police Car Dash Mounted Emergency Strobe Lights LED Screen Warning Support PTZ Camera

Police Car Dash Mounted Emergency Strobe Lights LED Screen Warning Support PTZ Camera
Police Car Dash Mounted Emergency Strobe Lights LED Screen Warning Support PTZ Camera

Large Image :  Police Car Dash Mounted Emergency Strobe Lights LED Screen Warning Support PTZ Camera

Product Details:

Place of Origin: China
Brand Name: Okaf
Certification: CE/FCC/RoHS
Model Number: OK-TBCT100GR-LED-DFP

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard Carton
Payment Terms: T/T, Paypal, Western Union, L/C, MoneyGram etc
Supply Ability: 2500pcs per month
Detailed Product Description
Car Models: Utility Trucks, Vehicles, Pilot Cars, Pickup Trucks, And Farm Machiner Usage: Warning Strobe Light Bar
Advantage: LED Screen Material: Plastic + Aluminium Alloy
Length: Customized According To Car Style Keyword: Police LED Light Bar With LED Screen
Volatge: 12V-24V Warranty: 1year
High Light:

led warning light bar

,

emergency vehicle light bars



Police Car LED Light Bar Roof Mounted LED Screen Strobe Warning With



PTZ Camera





Product description:



1. Warning light + car PTZ + LED lodging screen integrated design, the appearance of more refined, to avoid the general site of high-altitude crash badminton;

2. Support docking each network video recorder, thus access to various manufacturers platform;
3. Integrated LED invert flip screen, speed ≤ 60km display can be erected to use;
4. PTZ imported dot matrix infrared light from Germany, night vision distance of 120 meters;


5. Police lights using pipeline design, the appearance of new (red, blue, yellow optional) ;
6. Police lights using pipeline design, the appearance of new (red, blue, yellow optional);
7. PTZ built-in voltage regulator module, protection equipment stable and durable; 8,The highest resolution 2048X1536 (support docking Sony, Hikvision, UOB,



Parameters:



PTZ parameter
Model OK-TBCT100GR-LED-DFP
Horizontal preset speed 300°/S(Manual control0°~220°/S)
vertical preset speed 120°/S(Manual control0°~90°/S)
Horizontal angle 360°Unlimited
Up and down angle +90°~-90°
Preset patrolling track 256 preset positions
control method RS485 and RJ45 dual control protocol, baud rate from 2400Bps to 19200Bps optional
Network
Docking movement Hikvision, Sony, UOB, Hitachi and domestic network HD movement
Network interface RJ45 10Base-T/100Base-TX PoE(IEEE802.3af)
Maximum image size 1920×1080(By the movement pixel decision)
Frame rate 25/30 fps
Audio video compression H.264
Audio mode External active microphone or linear input, linear output (custom)
Network protocol IPv4, HTTP, FTP, RTSP, UPnP, DNS, NTP, RTP, TCP,UDP, IGMP, ICMP, ARP
Double stream Support
Video output BNC and RJ45 Dual output
Operating temperature -35°C~+65°C
Degree of protection IP66
Power DC10.5V~DC15V(3A car)
Weight 7KG
Infrared light parameters
Chroma 850nm
Search distance 120 meter
Infrared light number 3W*7
Long row of lights parameters
The main light source LED
Power source 48W
Color specification Red, yellow, blue optional
Siren power 100 watt,150 watt
length 1.2 meter
Power 12V/24V
Flip flip screen
Closed Dimensions (mm) 1194*525*172(Visual size:1024*256)
pixel * 32 dot matrix
Light-emitting points Level±60°,vertical±45°
Control Method Controller control
Visual distance(m) ≥150
light intensity(cd/㎡) ≥50000
Single screen can display the number of words 4
Movement
Model OK-TBCT100GR-LED-DFP13IP OK-TBCT100GR-LED-DFP-20IP OK-TBCT100GR-LED-DFP-30IP
Image Sensor 1/2.8 inch“Exmor”CMOS
Effective number of pixels About 1.3 million pixels About 2 million pixels About 3 million pixels
Lens 20x optical zoom, focal length 4.7-94mm; 30x optical zoom focal length 4.5-135mm
Minimum illumination Minimum illumination,color 0.05Lux @ (F1.6,AGC ON),black and white:0.01Lux @ (F1.6,AGC ON);
Back-end VCR compatible Standard ONVIF protocol, support for secondary development, support for Hikvision, UOB, Xiongmai, the United States Bell and other NVR
PTZ can choose another signal output AHD:200/130 SDI:300/200/130 Simulation of movement
